Precision Hydraulic Oil Filter Catalog – MOOG
Precision Hydraulic Oil Filter Catalog – MOOG thumbnail
×
Zoomed Product Image

Precision Hydraulic Oil Filter Catalog – MOOG

MOOG hydraulic oil filter replacement elements are expertly engineered to meet the stringent cleanliness standards required for high-performance servo valves and sophisticated aerospace flight control systems. Maintaining strict contamination control is vital to ensure long service life and prevent catastrophic system failure. Due to these precision components are extremely sensitive to microscopic particulates. Our aftermarket solutions utilize premium micro-glass media designed to achieve high filtering effectiveness, providing consistent protection even as global ISO test standards for particle measurement evolve.

quick information
  • Reference Price: 2.11 USD
  • Supply Ability: 5000 pcs per month
  • SKU: UF00001600
  • MPN: UF00001600
quote now

Technical Specification

Replacing BrandMOOG
Main Filter TypeHydraulic oil filter
MOQ10 ea
ImagePart NumberFilter TypeFilter MediaRemoval RatingRef. DimensionThreadSeal
PN AB1188 filter replacement AB1188 Pressure Filter Glass Fiber 3μm@β200, 5μm@β1000 OD78xID43xH428mm Viton
PN A811891 filter replacement A811891 Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD78xID43xH428mm Nitrile
PN A811881 filter replacement A811881 Pressure Filter Glass Fiber 3μm@β200, 5μm@β1000 OD78xID43xH428mm Nitrile
PN B645754A filter replacement B645754A Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD78xID43xH428mm Nitrile
PN B645744A filter replacement B645744A Pressure Filter Glass Fiber 3μm@β200, 5μm@β1000 OD78xID43xH428mm Nitrile
PN A811901 filter replacement A811901 Pressure Filter Glass Fiber 3μm@β200, 5μm@β1000 OD78xID43xH428mm Nitrile
PN A37012A filter replacement A37012A Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD78xID43xH330mm Nitrile
PN B645693A filter replacement B645693A Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD78xID43xH330mm Nitrile
PN A37012 filter replacement A37012 Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD78xID43xH330mm Nitrile
PN A37014 filter replacement A37014 Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD78xID43xH329mm Nitrile
PN B645753A filter replacement B645753A Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD78xID43xH329mm Nitrile
PN B645683A filter replacement B645683A Pressure Filter Glass Fiber 3μm@β200, 5μm@β1000 OD78xID43xH330mm Nitrile
PN 07198245A filter replacement 07198245A Pressure Filter Glass Fiber 3μm@β200, 5μm@β1000 OD78xID43xH330mm Nitrile
PN 07198245N filter replacement 07198245N Pressure Filter Glass Fiber 3μm@β200, 5μm@β1000 OD78xID43xH330mm Nitrile
PN 07160700A filter replacement 07160700A Pressure Filter Glass Fiber 20μm@β200, 22μm@β1000 OD78xID43xH207mm Nitrile
PN 07169700N filter replacement 07169700N Pressure Filter Glass Fiber 20μm@β200, 22μm@β1000 OD78xID43xH207mm Nitrile
PN 07169700A filter replacement 07169700A Pressure Filter Glass Fiber 20μm@β200, 22μm@β1000 OD78xID43xH207mm Nitrile
PN B645752A filter replacement B645752A Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD78xID43xH207mm Nitrile
PN 07168896N filter replacement 07168896N Pressure Filter Glass Fiber 5μm@β200, 7μm@β1000 OD78xID43xH207mm Nitrile
PN B645682A filter replacement B645682A Pressure Filter Glass Fiber 3μm@β200, 5μm@β1000 OD78xID43xH210mm Nitrile
PN B645742A filter replacement B645742A Pressure Filter Glass Fiber 3μm@β200, 5μm@β1000 OD78xID43xH207mm Nitrile
PN 07160712N filter replacement 07160712N Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD78xID43xH116mm Nitrile
PN 07160712A filter replacement 07160712A Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD78xID43xH116mm Nitrile
PN B645751A filter replacement B645751A Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD78xID43xH116mm Nitrile
PN P31255 filter replacement P31255 Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD51xID24xH207mm Nitrile
PN A31255A filter replacement A31255A Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD51xID24xH207mm Viton
PN A728871 filter replacement A728871 Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD51xID24xH207mm Nitrile
PN B645672A filter replacement B645672A Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD51xID24xH207mm Nitrile
PN B645662A filter replacement B645662A Pressure Filter Glass Fiber 3μm@β200, 5μm@β1000 OD51xID24xH207mm Nitrile
PN A720601 filter replacement A720601 Pressure Filter Glass Fiber 3μm@β200, 5μm@β1000 OD51xID24xH207mm Nitrile
PN A31254A filter replacement A31254A Pressure Filter Glass Fiber 3μm@β200, 5μm@β1000 OD51xID24xH207mm Viton
PN B645671A filter replacement B645671A Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD51xID24xH114mm Nitrile
PN A37016 filter replacement A37016 Pressure Filter Glass Fiber 5μm@β200, 7μm@β1000 OD50xID24xH116mm Nitrile
PN B645661A filter replacement B645661A Pressure Filter Glass Fiber 3μm@β200, 5μm@β1000 OD51xID24xH114mm Nitrile
PN B45274001 filter replacement B45274001 Pressure Filter Glass Fiber 3μm@β200, 5μm@β1000 OD51xID24xH114mm Nitrile
PN B645652A filter replacement B645652A Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD45xID25xH210mm Nitrile
PN 07160176N filter replacement 07160176N Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD45xID25xH210mm Nitrile
PN 160176 filter replacement 160176 Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD45xID25xH210mm Nitrile
PN 07160312N filter replacement 07160312N Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD45xID25xH209mm Nitrile
PN 07160312A filter replacement 07160312A Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD45xID25xH209mm Nitrile
PN B645712A filter replacement B645712A Pressure Filter Glass Fiber 5μm@β200, 7μm@β1000 OD45xID25xH209mm Nitrile
PN B645702A filter replacement B645702A Pressure Filter Glass Fiber 3μm@β200, 5μm@β1000 OD45xID25xH209mm Nitrile
PN 07160314N filter replacement 07160314N Pressure Filter Glass Fiber 3μm@β200, 5μm@β1000 OD45xID25xH209mm Nitrile
PN B645651A filter replacement B645651A Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD45xID25xH112mm Nitrile
PN 07160299N filter replacement 07160299N Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD45xID25xH112mm Nitrile
PN 07160299A filter replacement 07160299A Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD45xID25xH112mm Nitrile
PN 07160331A filter replacement 07160331A Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD45xID25xH112mm Nitrile
PN 07160311N filter replacement 07160311N Pressure Filter Glass Fiber 10μm@β200, 12μm@β1000 OD45xID25xH112mm Nitrile
PN B645711A filter replacement B645711A Pressure Filter Glass Fiber 5μm@β200, 7μm@β1000 OD45xID25xH112mm Nitrile
PN 7160313 filter replacement 7160313 Pressure Filter Glass Fiber 5μm@β200, 7μm@β1000 OD45xID25xH112mm Nitrile
